Elite CAN HUB 4 Port DTM-4 - HT-159000

Haltech Elite CAN Hub — 4 Port DTM-4 (HT-159000)

The part that turns one CAN port into three. An Elite ECU has a single CAN connector, and the moment you add a wideband controller, a dash, or a boost control module you've used it up. This hub expands the network so those devices can coexist.

Plug and play — direct compatible with an Elite ECU CAN port or an Elite ECU harness CAN connector, so there's no splicing or terminating resistors to sort out. Two or more hubs can be daisy-chained together when a build outgrows three devices.

DTM-4 connectors throughout, which is the same sealed Deutsch connector the rest of the Elite ecosystem uses.

Supports up to three CAN devices.

Plan for this early. Most people buy the hub after they've already run the harness and discovered they're one port short. If the build includes a dash, a wideband, or any CAN expansion module, budget for it up front.

Includes the Elite 4-port CAN hub and a 300mm (12") Elite CAN cable, DTM-4 to DTM-4.

Not CARB legal. Not for sale in California.
